KiwiSat® Glue On Series

  • Product Type Icon Tag

The KiwiSat® 202 series series are marine Argos transmitters for glue on attachment

The KiwiSat® Glue-On series is available in models weighing from as little as 34g and are designed to be compact with minimal frontal area to minimise drag. Despite their small size, these transmitters are designed to withstand the harsh marine environment.


  • Wet/dry sensor, flexible scheduling and haul-out mode
  • DIVE data includes max. depth, time and TAD (Time At Depth) index. (excludng K2G 173A)
  • Product Specifications

    Model Weight (g) Size (mm) Max depth Heavy duty Estimated Life [2] (days)
      in air in seawater [1] (LxWxH) (m)   Standard DIVE DepthTemp
    K2G 173A 34 17.6 60 x 27 x 17 500 No 292
    K2G 158C 40 8.7 56 x 26 x 21 500 No 195 181 94
    K2G 276A 112 19.3 78 x 43 x 27 2000 No 575 547 330
    K2G 276B 120 TBD 82 x 44 x 33 2000 Yes 575 547 330
    K2G 376E 240 TBD 136 x 44 x 59 2000 Yes 863 820 495
    K2G 576E 360 TBD 138 x 78 x 50 2000 Yes 1439 1366 825

    1. Assuming the density of seawater is 1024 kg/m^3.
    2. Estimated life based on 200 transmissions per day.
    Features and specifications subject to change without notice

    Technical Specifications:
    Argos transmit power: 500mW
    Operating temperature range: – 20˚C to 50˚C

    Standard Sensors:
    Wet/dry sensor
    Temperature sensor range: -50˚C to 75˚C
    Temperature sensor accuracy: +/- 0.5˚C
    Temperature sensor resolution: 0.25˚C

    DIVE Sensors:
    Calibrated sensor range: -5˚C to 40˚C
    Depth sensor ranges: 200m, 500m, 2000m
    Depth sensor accuracy: ±1% of Full Scale
    Depth sensor resolution: ~0.025% of Full Scale
    Temperature sensor range: -40˚C to 60˚C
    Temperature sensor accuracy: ±0.2˚C
    Temperature sensor resolution: better than 0.05˚C
